Maintenance costs

Perhaps the folding doors main strength

The Ecolid door is optimised to require a minimum level of service. During normal use, we prescribe an 18-month interval between each service on motor operated doors. The service that will be performed is very simple; in principle it involves checking screws and bolted connections. This is a small job that can be managed without the need of specialised door technicians. The function of the door’s anti-crushing protective strips, photocells and load monitor should also be checked annually. These actions are also simple and can be performed without professional assistance.

2.198 SEK

ECOLID – manuell

14.128 SEK

ECOLID – motordriven

33.870 SEK

TAKSKJUTSPORT – motordriven

Service and call out cost :
SEK 0 each time

Service and call out cost
every 18 months:
SEK 1,155 each time, 6 times/10 years
Service and call out cost
every 12 months:
SEK 1,155 each time, 10 times/10 years

Inspection by inspection body:
SEK 0 each time

Inspection by inspection body:
SEK 1,000 each time, 5 times/10 years

Inspection by inspection body:
SEK 1,000 each time, 5 times/10 years

Replacing Teflon bushings and sealing strips:
Normally replaced once every 10 years
Material SEK 398, labour SEK 1,800

Replacing torsion springs:
Normally replaced after 25,000 openings
Material SEK 10,400, labour SEK 3,600

Total cost = SEK 14,000


Replacing wires, side rolls and side seal:
Normally replaced after 50,000 openings
Material SEK 1,520, labour SEK 1,800

 Total cost 10 years = SEK 2,198  Total cost 10 years = SEK 14,128 Total cost 10 years = SEK 33,870


Prerequisites:
Doors 4×4 m, 20 openings per day, 250 days/year, hourly rate SEK 600, distance to service firm 30 km, SEK 850/km, 10 year usage. It is assumed that inspections by inspection bodies are performed in connection with other inspection in the same operating site. Ecolid’s material costs according to Prido AB’s spare parts price list. The overhead door’s spare parts prices are according to information from an established service firm.
