Brackets mounted on the door leaves
Electrogalvanized steel or aluminum.
On outward-opening doors, the steel fittings are also powder-coated.
Argon-filled D4-12 insulated-glass panes in six different standard sizes.
Standard chest height approx. 1,070 mm.
7-year warranty against condensation between glass panes.
Window frames made from natural anodized aluminum profiles with
Pedestrian door option
One door leaf can be converted into a pedestrian door if
the door height is max. 3,200 mm. The pedestrian door section is delivered
with a Dorma DL 919-50 lock housing and Habo Atlanta lever handle.
The strike plate is fitted on the side leaf, which is also equipped with
a garage bolt for padlocking.
Natural anodized aluminum handle.
Multi-size adjustable steel hinges.
Electrogalvanized on inward-opening hinged doors and
electrogalvanized and powder-coated on outward-opening doors.
Lubrication-free Teflon bushings. Screws into door surround.
Lifting hinges (optional)
Raises the door during opening by 10
mm. Suitable for uneven floors. Creates a good seal
when closed and enables soft and smooth opening
without unnecessary wear on the bottom seal.
Process-laminated sandwich panels. 50 mm thickness.
Max. size of individual door leaf 1250 x 4600 mm.
Frame made from natural anodized aluminum profiles.
Cast steel reinforcements as attachment points for hinges, controls, etc.
Made of steel, concrete or wood. At least 3 mm steel for inward opening and at least 4 mm for outward opening.
3 different screw kits depending on the type of door surround.
